| FIG | ITEM | SPEC. | Voltage (V) | Wattage (W) | Luminous Flux (Lm) | Average Life (H) | Base |
| ZC22 | H8 | 12V35W | 13.2 | MAX43 | 800±15% | 500 | PGJ19-1 |
| ZC23 | H9 | 12V65W | 13.2 | MAX73 | 2100±15% | 500 | PGJ19-5 |
| ZC24 | H10 | 12V42W | 13.2 | MAX50 | 850±15% | 500 | PY20D |
| ZC25 | H11 | 12V55W | 13.2 | MAX62 | 1250±15% | 500 | PGJ19-2 |
| ZC25 | H11 | 24V70W | 28.0 | MAX80 | 1600±15% | 500 | PGJ19-2 |
| ZC26 | H13 | 12V60/55W | | | | | 27P |
| FIG | ITEM | SPEC. | Voltage (V) | Wattage (W) | Luminous Flux (Lm) | Average Life (H) | Base |
| ZC22 | H8 | 12V35W | 13.2 | MAX43 | 800±15% | 500 | PGJ19-1 |
| ZC23 | H9 | 12V65W | 13.2 | MAX73 | 2100±15% | 500 | PGJ19-5 |
| ZC24 | H10 | 12V42W | 13.2 | MAX50 | 850±15% | 500 | PY20D |
| ZC25 | H11 | 12V55W | 13.2 | MAX62 | 1250±15% | 500 | PGJ19-2 |
| ZC25 | H11 | 24V70W | 28.0 | MAX80 | 1600±15% | 500 | PGJ19-2 |
| ZC26 | H13 | 12V60/55W | | | | | 27P |
